Laboratories

Civil Computer Centre

Advanced Highway lab

Equipment : ENKAY Universal Testing /c Capacity 100 T with accessories Aggregate Impact testing machine with accessories Beam balance, capacity 5 kg.,Devals Attrition testing machine,Ring Ball Apparatus with Accessories,ABEL Flash point apparatus with Accessories,Redwood Viscometer with Accessories,ABEL Flash point apparatus with Accessories,Redwood Viscometer with Accessories,Marshall stability test apparatus with accessories,Compression testing m/c, Thcikness gauge Sample divider Flash & fire point apparatus Marsh cone (funnel) viscometer Automatic Bituminous compactor Aggregate specific Gravity test apparatus (Digital ) Weighting machine (Electronic Balance) 100kg X 10 kg Softening point test apparatus (semi-automatic) Water bath, rectangular Doublewalled Sieve set GI frame Aggregate impact tester with Blow counter Thin film oven Seive set G.I. Frame British pendulum connon manning cum cannon fenske viscometer bath with vacuum pump Benkelman beam with digital dial Asphalt content tester Asphalt mixer 5 ltr capacity Automatic marshall stability test apparatus (digital) Wheel Rut Tester Length Gauge induction Heater 2000W Automatic marshall stability test apparatus (digital) Wheel Rut Tester Accelerated stone polishing machine

Environmental Lab

Equipment : Varimex Photo Colorimeter Type KF-1 NR, cycles,Turbidity Rod,Residual Chlorine testing set Chloroscope,Conductivity Bridge,Alkalinity Hardness Test Kit M-2,Universal P.H Meter Type OP 204,Orsat Gas Analyzer Apparatus,Toshniwal CM11 Turbidity Meter Jackson Turbidity meter,Refrigerator Cap. 165 Lit,Aplab Lab. Floculator Type IE-5 6 stirrers,Elico Dissolved Oxygen Analyzer model PE 130,B.O.D. System Oxitop - 6 with 6 Sensors Stirrer), Food organic Waste to compost m/c Construction of Shed for food Composting M/c, Sodium Hydroxide/Castie Soda Flakes (NaOH) Commercial Sodium meta silicate Pentahdrates (METSIL)

Surveying Lab

Equipment : UNIVERSAL THEODOLITE N1-T2 Universal Theodolite (Wild Model) with Telescopic stand and standard accessories,Abney levels,Box Sextant,Clinometer Delisles pattern,Compass Prismatic 112 mm dia,Contact Goniometer Model G.R,Ghat Tracer,Levels,LATHE MACHINE Austrian make EMCO UNIMAT,Mirror lens Stereoscope Model Z,Optical square, Optical square with Prism,Pocket Stereoscope,Penta Graph in wooden box,Pocket compass German make 4 cmdia (Radium big size with lock),Binocular 7x50 Japan make in leather case with right eye adjustment and center focusing wheel, Geo Max DGPS Zenith 25 Pro ( 1 Base + 1 Rover) Leico Disto Meter 100 M Thermal Payload (640 x512) optical Zoom Sensor 30X workstation UAV with RTK System

Fluid Mechanics Lab

Equipment : Meta-centric Height Assembly with Two sets of slotted wt. 50 gms each,Pitot Tube,Current meter,Flow Nozzle Meter B.K. Type of standard design (DIN 1952) with 25 mm dia. pipe 15 mm dia. of nozzle complete with measuring tank,Triple cut section (5 models) and valves,Hydraulic Flumes Tilting type with all accessories like diff. type of spill ways weirs, and centrifugal pump of 7.5 HP fitted with venturimeter manometers,Centrifugal pump with motor to supply of water to pelton wheel turbine with accessories like venturimeter etc,Calibration Test Rig. Measuring discharge of water through venturimeters and orifice meters and accessories, Bernoulli Theorem Apparatus Discharge over Notches Impact of Jet on Vanes Meta centric Height Apparatus Reynolds Apparatus

Strength of Materials Lab

Equipment : Universal Testing M/c 40 T Cap,Compression Testing M/c 200 T Cp,Flexure Testing M/c,Torsion Testing M/c,Impact Testing M/c,Fatique Testing M/c,Brinell cum Hardness Testing M/c,RocK-well Hardness Testing M/c,Universal Testing M/c (Computerized) 100T,Compression Testing M/c (Computerized)

Structural Engg Lab

Equipment : Universal Testing M/c 100 T. Cap,Loading Frame 100 T Cap,Ultrasonic pulse Velocity meter (NDT),Ultrasonic Concrete Tester,Compression Testing M/c 200 T Cp.,Flexure Testing M/c,Torsion Testing M/c,Impact Testing M/c,Fatique Testing M/c,Brinell cum Hardness Testing M/c,RocK-well Hardness Testing M/c,Universal Testing M/c (Computerized) 100T,Compression Testing M/c (Computerized)

Geotech Engg & Rock Mech Lab

Equipment : Triaxial Compression Test Apparatus,Unconfined Compression Test Apparatus,Direct Shear Test Apparatus,C.B.R. Test App,Consolidation Test Apparatus,Plate Load Test Apparatus,Standard Penetration Test Apparatus,Sieve Shaker,Slake Durability Apparatus,Rock Core Drilling M/c, Flexi wall Permeability Apparatus with Toxie Interface Digital Consolidation System Automatic CBR Test Apparatus Swell Testing Apparatus Unconfined Compression Apparatus Sieve Shaker Motorized Impact Moister Meter Liquid Limit Device (Motorized)

Engineering Mechanics Lab

To verify law of Polygon of forces., To find the reaction at the supports of a Simply Supported Beam and verify the law of Superposition of Forces., To determine the Coefficient of friction between different surfaces using a horizontal plane., To find the Coefficient of friction between Rope and Drum., To verify Shear Force at a given section of a Simply Supported Beam., To verify Bending Moment at a given section of a Simply Supported Beam., To find the Consistency of cement., To find the Initial & Final Setting time of cement, To find compressive strength of concrete cube., To find the Water Absorption and compressive strength of Brick.
Equipment : Compound Pendulum. Inclined Plane, Atwood Machine, Simple Pendulum, Fly wheel App., Compression and Extension of spring App., Centrifugal force App., Coil Friction App., Coil Friction App., Triangle and Parallelograms of forces App., Parallel Force App. (Beam Reaction App. ) Single Purchase Crabe, Double Purchase Crabe, Worm & Worm Wheel, Worm & Worm, polygon of forces App., Simple Screw Jack, Universal Force Table Complete, Bell Crank Lever Complete, Screw Jack Complete, Epicycke
